Plastic Processed:
PP, PC, PET
Condition:
New
Style:
Horizontal
Distance Between Tie Bars(Width)(mm):
355mm
Distance Between Tie Bars(Height)(mm):
315mm
Mold Height(mm):
150 - 380 Mm
Ejector Stroke(mm):
70 Mm
Ejector Force(kN):
27 KN
Theoretical Shot Volume(cm³):
190 Cm³
Injection Rate (g/s):
78 G/s
Machine Type:
Hydraulic
Injection Weight (g):
173 G
Screw Speed (rpm):
1 - 200 Rpm
Screw Diameter (mm):
38 Mm
Distance Between Tie Bars:
355mm*315mm
Weight (KG):
2700
Type:
Tube Head Injection
Place Of Origin:
Zhejiang, China
Open Stroke(mm):
280 Mm
Model Number:
FHG-100
Brand Name:
FUHONG
Power (kW):
9 KW
Warranty:
2 Years
Key Selling Points:
Energy Saving
Applicable Industries:
Manufacturing Plant
Showroom Location:
None
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
1 Year
Core Components:
Motor, Pump, Other, Pressure Vessel
After-sales Service Provided:
Engineers Available To Service Machinery Overseas, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
Plastic Type:
Thermoplastic
Automatic:
Yes
Space Between Tie Bar:
355mm*315mm
Mould Thickness:
150mm-380mm
Ejector Stroke:
70mm
Ejector Force:
27kn
System Pressure:
16Mpa
Pump Motor:
9kw
Heating Capacity:
6.9kw
After Warranty Service:
Online Support
Local Service Location:
None
Certification:
CE TUV
